RoadMAX RX1

Exceptional clarity and comfort

Replace Cobraheads up to 200W
2,840-13,000 lumens, 30-100W

RX1_Isolated

Meet the RoadMAX RX1

RoadMax RX1 delivers high-performance roadway distributions coupled with exceptional glare control. Use for municipal streets, public roadways, campuses, industrial parks, parking lots and more. Starting at 30W, 2700K and with the secondary lens, the RX1 is an ideal building-block for creating a neighborhood ambiance that incorporates visual clarity and comfort.

This sleek, utility-grade luminaire is easily configurable to meet a multitude of application requirements including Dark Sky ordinances. Options and features include Type II, Type III, Type IV and Type V distributions, field adjustable wattage selector, light trespass shields, and 20kV/10kA surge protection. Customize to include Evluma’s Photocontrol Failsafe or ConnectLED, Evluma’s Bluetooth app for wireless lighting controls, enables dimming and dimming schedules without the need for a network.

RX1-Carroll-Arkansas-1-scaled
RX1_Bottom

Features

20kV/10kA Category High C surge protection
120-277 VAC, 60hz
L70 (TM-21) >100,000 hrs
IP66 Glass optics
Enclosed, 2-bolt mounting bracket
Tool-less access panel
Easy-access, 3-positon terminal block
Wildlife guard
Rugged, powder-coated aluminum housing
Thermally efficient housing design
Bubble level

Options

Secondary lens for Glare Control
FAO (Field Adjustable Output) wattage selector
Photocontrol Failsafe
ConnectLED
Evluma integrated photocontrol
Leads: 6’, 10’, 20’
NEMA label
Light trespass shields
Colors: Black, Bronze, Gray
Coastal Package (anti-corrosion)
Shorting cap and more...

Data Sheets

Warranty

The RoadMAX has a 10-year Warranty. Standard.

Commanding Roadway Performance

To achieve uniform lighting on the road, visual acuity and adequate contrast for drivers, luminaires must be able to meet every curve in the road. Don’t sweat the specs. RoadMax roadway luminaires are designed with stringent roadway specifics in mind. Unparalleled optical performance begins with Evluma’s custom, glass optics. A robust housing that sheds heat and debris guarantees a long bright LED life, 20kV/10kA extreme surge protection defends again hostile environments and unmatched features mean unrivaled lifetime savings. And it’s all backed by a comprehensive 10-year warranty.

rx1_commanding

Photocontrol Failsafe

A failed photocontrol means a trip to the pole, and all the costs and disruptions that come with it. With Photocontrol Failsafe, your RoadMax streetlight will automatically recover from a failed photocontrol with zero intervention. Evluma’s proprietary Photocontrol Failsafe technology is available as an option for RoadMax.

Glare and Light Trespass Control

Recognizing that glare is a significant challenge in the roadway environment, Evluma set out to design a luminaire that delivers industry-leading glare control without compromising performance. Limiting Disability Glare is critical. Quality lighting improves detection (stopping) distances and contributes to safer roads for drivers and pedestrians. An elegant combination of glass and specialty acrylic lenses creates best-in-class uniformity and a measurable reduction in Disability Glare. Pair with a streamlined, low-profile set of trespass shields and achieve a harmonious community lighting strategy. Don’t simply direct glare away, eliminate both Glare and Glare complaints.

Family Watts CCT TYPE Lens Config Photocontrol
RX13027K, 3K, 4K, 5KII, III, IV, V+ glare controlIntegrated, 3-pin, 7-pin
RX14027K, 3K, 4K, 5KII, III, IV, V+ glare controlIntegrated, 3-pin, 7-pin
RX15027K, 3K, 4K, 5KII, III, IV, V+ glare controlIntegrated, 3-pin, 7-pin
RX16027K, 3K, 4K, 5KII, III, IV, V+ glare controlIntegrated, 3-pin, 7-pin
RX17027K, 3K, 4K, 5KII, III, IV, V+ glare controlIntegrated, 3-pin, 7-pin
RX18027K, 3K, 4K, 5KII, III, IV, V+ glare controlIntegrated, 3-pin, 7-pin
RX19027K, 3K, 4K, 5KII, III, IV, V+ glare controlIntegrated, 3-pin, 7-pin
RX110027K, 3K, 4K, 5KII, III, IV, V+ glare controlIntegrated, 3-pin, 7-pin

The RX1 Model Overview

Select from Type II, Type III, Type IV and Type V distributions and CCT ranging 2700K to 5000K. Add a secondary lens for enhanced glare control field. RoadMax has multiple options for controls including traditional 3-pin and 7-pin photocontrol sockets. 0-10V dimming supports adaptive lighting and networked nodes. Simplify and shorten installation time with Evluma’s robust integrated photocontrol.

Unique options include Evluma’s Photocontrol Failsafe, that eliminates truck rolls for photocontrol failures, or ConnectLED, Evluma’s Bluetooth app for wireless lighting controls.

RoadMAX RX1 IES Files

Download IES Package     Download PDF Package


RX1 030 C3 T2 G0 - RX Small, 30W, 3000K, Type II
RX1 030 C3 T2 G1 - RX Small, 30W, 3000K, Type II, glare control
RX1 030 C4 T2 G0 - RX Small, 30W, 4000K, Type II
RX1 030 C4 T2 G1 - RX Small, 30W, 4000K, Type II, glare control
RX1 030 C5 T2 G0 - RX Small, 30W, 5000K, Type II
RX1 030 C5 T2 G1 - RX Small, 30W, 5000K, Type II, glare control
RX1 030 C7 T2 G0 - RX Small, 30W, 2700K, Type II
RX1 030 C7 T2 G1 - RX Small, 30W, 2700K, Type II, glare control
RX1 040 C3 T2 G0 - RX Small, 40W, 3000K, Type II
RX1 040 C3 T2 G1 - RX Small, 40W, 3000K, Type II, glare control
RX1 040 C4 T2 G0 - RX Small, 40W, 4000K, Type II
RX1 040 C4 T2 G1 - RX Small, 40W, 4000K, Type II, glare control
RX1 040 C5 T2 G0 - RX Small, 40W, 5000K, Type II
RX1 040 C5 T2 G1 - RX Small, 40W, 5000K, Type II, glare control
RX1 040 C7 T2 G0 - RX Small, 40W, 2700K, Type II
RX1 040 C7 T2 G1 - RX Small, 40W, 2700K, Type II, glare control
RX1 050 C3 T2 G0 - RX Small, 50W, 3000K, Type II
RX1 050 C3 T2 G1 - RX Small, 50W, 3000K, Type II, glare control
RX1 050 C4 T2 G0 - RX Small, 50W, 4000K, Type II
RX1 050 C4 T2 G1 - RX Small, 50W, 4000K, Type II, glare control
RX1 050 C5 T2 G0 - RX Small, 50W, 5000K, Type II
RX1 050 C5 T2 G1 - RX Small, 50W, 5000K, Type II, glare control
RX1 050 C7 T2 G0 - RX Small, 50W, 2700K, Type II
RX1 050 C7 T2 G1 - RX Small, 50W, 2700K, Type II, glare control
RX1 060 C3 T2 G0 - RX Small, 60W, 3000K, Type II
RX1 060 C3 T2 G1 - RX Small, 60W, 3000K, Type II, glare control
RX1 060 C4 T2 G0 - RX Small, 60W, 4000K, Type II
RX1 060 C4 T2 G1 - RX Small, 60W, 4000K, Type II, glare control
RX1 060 C5 T2 G0 - RX Small, 60W, 5000K, Type II
RX1 060 C5 T2 G1 - RX Small, 60W, 5000K, Type II, glare control
RX1 060 C7 T2 G0 - RX Small, 60W, 2700K, Type II
RX1 060 C7 T2 G1 - RX Small, 60W, 2700K, Type II, glare control
RX1 070 C3 T2 G0 - RX Small, 70W, 3000K, Type II
RX1 070 C3 T2 G1 - RX Small, 70W, 3000K, Type II, glare control
RX1 070 C4 T2 G0 - RX Small, 70W, 4000K, Type II
RX1 070 C4 T2 G1 - RX Small, 70W, 4000K, Type II, glare control
RX1 070 C5 T2 G0 - RX Small, 70W, 5000K, Type II
RX1 070 C5 T2 G1 - RX Small, 70W, 5000K, Type II, glare control
RX1 070 C7 T2 G0 - RX Small, 70W, 2700K, Type II
RX1 070 C7 T2 G1 - RX Small, 70W, 2700K, Type II, glare control
RX1 080 E3 T2 G0 - RX Small, 80W, 3000K, Type II
RX1 080 E3 T2 G1 - RX Small, 80W, 3000K, Type II, glare control
RX1 080 E4 T2 G0 - RX Small, 80W, 4000K, Type II
RX1 080 E4 T2 G1 - RX Small, 80W, 4000K, Type II, glare control
RX1 080 E5 T2 G0 - RX Small, 80W, 5000K, Type II
RX1 080 E5 T2 G1 - RX Small, 80W, 5000K, Type II, glare control
RX1 080 E7 T2 G0 - RX Small, 80W, 2700K, Type II
RX1 080 E7 T2 G1 - RX Small, 80W, 2700K, Type II, glare control
RX1 090 E3 T2 G0 - RX Small, 90W, 3000K, Type II
RX1 090 E3 T2 G1 - RX Small, 90W, 3000K, Type II, glare control
RX1 090 E4 T2 G0 - RX Small, 90W, 4000K, Type II
RX1 090 E4 T2 G1 - RX Small, 90W, 4000K, Type II, glare control
RX1 090 E5 T2 G0 - RX Small, 90W, 5000K, Type II
RX1 090 E5 T2 G1 - RX Small, 90W, 5000K, Type II, glare control
RX1 090 E7 T2 G0 - RX Small, 90W, 2700K, Type II
RX1 090 E7 T2 G1 - RX Small, 90W, 2700K, Type II, glare control
RX1 100 E3 T2 G0 - RX Small, 100W, 3000K, Type II
RX1 100 E3 T2 G1 - RX Small, 100W, 3000K, Type II, glare control
RX1 100 E4 T2 G0 - RX Small, 100W, 4000K, Type II
RX1 100 E4 T2 G1 - RX Small, 100W, 4000K, Type II, glare control
RX1 100 E5 T2 G0 - RX Small, 100W, 5000K, Type II
RX1 100 E5 T2 G1 - RX Small, 100W, 5000K, Type II, glare control
RX1 100 E7 T2 G0 - RX Small, 100W, 2700K, Type II
RX1 100 E7 T2 G1 - RX Small, 100W, 2700K, Type II, glare control

Download IES Package     Download PDF Package


RX1 030 C3 T3 G0 - RX Small, 30W, 3000K, Type III
RX1 030 C3 T3 G1 - RX Small, 30W, 3000K, Type III, glare control
RX1 030 C4 T3 G0 - RX Small, 30W, 4000K, Type III
RX1 030 C4 T3 G1 - RX Small, 30W, 4000K, Type III, glare control
RX1 030 C5 T3 G0 - RX Small, 30W, 5000K, Type III
RX1 030 C5 T3 G1 - RX Small, 30W, 5000K, Type III, glare control
RX1 030 C7 T3 G0 - RX Small, 30W, 2700K, Type III
RX1 030 C7 T3 G1 - RX Small, 30W, 2700K, Type III, glare control
RX1 040 C3 T3 G0 - RX Small, 40W, 3000K, Type III
RX1 040 C3 T3 G1 - RX Small, 40W, 3000K, Type III, glare control
RX1 040 C4 T3 G0 - RX Small, 40W, 4000K, Type III
RX1 040 C4 T3 G1 - RX Small, 40W, 4000K, Type III, glare control
RX1 040 C5 T3 G0 - RX Small, 40W, 5000K, Type III
RX1 040 C5 T3 G1 - RX Small, 40W, 5000K, Type III, glare control
RX1 040 C7 T3 G0 - RX Small, 40W, 2700K, Type III
RX1 040 C7 T3 G1 - RX Small, 40W, 2700K, Type III, glare control
RX1 050 C3 T3 G0 - RX Small, 50W, 3000K, Type III
RX1 050 C3 T3 G1 - RX Small, 50W, 3000K, Type III, glare control
RX1 050 C4 T3 G0 - RX Small, 50W, 4000K, Type III
RX1 050 C4 T3 G1 - RX Small, 50W, 4000K, Type III, glare control
RX1 050 C5 T3 G0 - RX Small, 50W, 5000K, Type III
RX1 050 C5 T3 G1 - RX Small, 50W, 5000K, Type III, glare control
RX1 050 C7 T3 G0 - RX Small, 50W, 2700K, Type III
RX1 050 C7 T3 G1 - RX Small, 50W, 2700K, Type III, glare control
RX1 060 C3 T3 G0 - RX Small, 60W, 3000K, Type III
RX1 060 C3 T3 G1 - RX Small, 60W, 3000K, Type III, glare control
RX1 060 C4 T3 G0 - RX Small, 60W, 4000K, Type III
RX1 060 C4 T3 G1 - RX Small, 60W, 4000K, Type III, glare control
RX1 060 C5 T3 G0 - RX Small, 60W, 5000K, Type III
RX1 060 C5 T3 G1 - RX Small, 60W, 5000K, Type III, glare control
RX1 060 C7 T3 G0 - RX Small, 60W, 2700K, Type III
RX1 060 C7 T3 G1 - RX Small, 60W, 2700K, Type III, glare control
RX1 070 C3 T3 G0 - RX Small, 70W, 3000K, Type III
RX1 070 C3 T3 G1 - RX Small, 70W, 3000K, Type III, glare control
RX1 070 C4 T3 G0 - RX Small, 70W, 4000K, Type III
RX1 070 C4 T3 G1 - RX Small, 70W, 4000K, Type III, glare control
RX1 070 C5 T3 G0 - RX Small, 70W, 5000K, Type III
RX1 070 C5 T3 G1 - RX Small, 70W, 5000K, Type III, glare control
RX1 070 C7 T3 G0 - RX Small, 70W, 2700K, Type III
RX1 070 C7 T3 G1 - RX Small, 70W, 2700K, Type III, glare control
RX1 080 E3 T3 G0 - RX Small, 80W, 3000K, Type III
RX1 080 E3 T3 G1 - RX Small, 80W, 3000K, Type III, glare control
RX1 080 E4 T3 G0 - RX Small, 80W, 4000K, Type III
RX1 080 E4 T3 G1 - RX Small, 80W, 4000K, Type III, glare control
RX1 080 E5 T3 G0 - RX Small, 80W, 5000K, Type III
RX1 080 E5 T3 G1 - RX Small, 80W, 5000K, Type III, glare control
RX1 080 E7 T3 G0 - RX Small, 80W, 2700K, Type III
RX1 080 E7 T3 G1 - RX Small, 80W, 2700K, Type III, glare control
RX1 090 E3 T3 G0 - RX Small, 90W, 3000K, Type III
RX1 090 E3 T3 G1 - RX Small, 90W, 3000K, Type III, glare control
RX1 090 E4 T3 G0 - RX Small, 90W, 4000K, Type III
RX1 090 E4 T3 G1 - RX Small, 90W, 4000K, Type III, glare control
RX1 090 E5 T3 G0 - RX Small, 90W, 5000K, Type III
RX1 090 E5 T3 G1 - RX Small, 90W, 5000K, Type III, glare control
RX1 090 E7 T3 G0 - RX Small, 90W, 2700K, Type III
RX1 090 E7 T3 G1 - RX Small, 90W, 2700K, Type III, glare control
RX1 100 E3 T3 G0 - RX Small, 100W, 3000K, Type III
RX1 100 E3 T3 G1 - RX Small, 100W, 3000K, Type III, glare control
RX1 100 E4 T3 G0 - RX Small, 100W, 4000K, Type III
RX1 100 E4 T3 G1 - RX Small, 100W, 4000K, Type III, glare control
RX1 100 E5 T3 G0 - RX Small, 100W, 5000K, Type III
RX1 100 E5 T3 G1 - RX Small, 100W, 5000K, Type III, glare control
RX1 100 E7 T3 G0 - RX Small, 100W, 2700K, Type III
RX1 100 E7 T3 G1 - RX Small, 100W, 2700K, Type III, glare control

Download IES Package     Download PDF Package


RX1-030-C3-T4-G0 - RX Small, 30W, 3000K, Type IV
RX1-030-C3-T4-G1 - RX Small, 30W, 3000K, Type IV, glare control
RX1-030-C4-T4-G0 - RX Small, 30W, 4000K, Type IV
RX1-030-C4-T4-G1 - RX Small, 30W, 4000K, Type IV, glare control
RX1-030-C5-T4-G0 - RX Small, 30W, 5000K, Type IV
RX1-030-C5-T4-G1 - RX Small, 30W, 5000K, Type IV, glare control
RX1-030-C7-T4-G0 - RX Small, 30W, 2700K, Type IV
RX1-030-C7-T4-G1 - RX Small, 30W, 2700K, Type IV, glare control
RX1-040-C3-T4-G0 - RX Small, 40W, 3000K, Type IV
RX1-040-C3-T4-G1 - RX Small, 40W, 3000K, Type IV, glare control
RX1-040-C4-T4-G0 - RX Small, 40W, 4000K, Type IV
RX1-040-C4-T4-G1 - RX Small, 40W, 4000K, Type IV, glare control
RX1-040-C5-T4-G0 - RX Small, 40W, 5000K, Type IV
RX1-040-C5-T4-G1 - RX Small, 40W, 5000K, Type IV, glare control
RX1-040-C7-T4-G0 - RX Small, 40W, 2700K, Type IV
RX1-040-C7-T4-G1 - RX Small, 40W, 2700K, Type IV, glare control
RX1-050-C3-T4-G0 - RX Small, 50W, 3000K, Type IV
RX1-050-C3-T4-G1 - RX Small, 50W, 3000K, Type IV, glare control
RX1-050-C4-T4-G0 - RX Small, 50W, 4000K, Type IV
RX1-050-C4-T4-G1 - RX Small, 50W, 4000K, Type IV, glare control
RX1-050-C5-T4-G0 - RX Small, 50W, 5000K, Type IV
RX1-050-C5-T4-G1 - RX Small, 50W, 5000K, Type IV, glare control
RX1-050-C7-T4-G0 - RX Small, 50W, 2700K, Type IV
RX1-050-C7-T4-G1 - RX Small, 50W, 2700K, Type IV, glare control
RX1-060-C3-T4-G0 - RX Small, 60W, 3000K, Type IV
RX1-060-C3-T4-G1 - RX Small, 60W, 3000K, Type IV, glare control
RX1-060-C4-T4-G0 - RX Small, 60W, 4000K, Type IV
RX1-060-C4-T4-G1 - RX Small, 60W, 4000K, Type IV, glare control
RX1-060-C5-T4-G0 - RX Small, 60W, 5000K, Type IV
RX1-060-C5-T4-G1 - RX Small, 60W, 5000K, Type IV, glare control
RX1-060-C7-T4-G0 - RX Small, 60W, 2700K, Type IV
RX1-060-C7-T4-G1 - RX Small, 60W, 2700K, Type IV, glare control
RX1-070-C3-T4-G0 - RX Small, 70W, 3000K, Type IV
RX1-070-C3-T4-G1 - RX Small, 70W, 3000K, Type IV, glare control
RX1-070-C4-T4-G0 - RX Small, 70W, 4000K, Type IV
RX1-070-C4-T4-G1 - RX Small, 70W, 4000K, Type IV, glare control
RX1-070-C5-T4-G0 - RX Small, 70W, 5000K, Type IV
RX1-070-C5-T4-G1 - RX Small, 70W, 5000K, Type IV, glare control
RX1-070-C7-T4-G0 - RX Small, 70W, 2700K, Type IV
RX1-070-C7-T4-G1 - RX Small, 70W, 2700K, Type IV, glare control
RX1-080-E3-T4-G0 - RX Small, 80W, 3000K, Type IV
RX1-080-E3-T4-G1 - RX Small, 80W, 3000K, Type IV, glare control
RX1-080-E4-T4-G0 - RX Small, 80W, 4000K, Type IV
RX1-080-E4-T4-G1 - RX Small, 80W, 4000K, Type IV, glare control
RX1-080-E5-T4-G0 - RX Small, 80W, 5000K, Type IV
RX1-080-E5-T4-G1 - RX Small, 80W, 5000K, Type IV, glare control
RX1-080-E7-T4-G0 - RX Small, 80W, 2700K, Type IV
RX1-080-E7-T4-G1 - RX Small, 80W, 2700K, Type IV, glare control
RX1-090-E3-T4-G0 - RX Small, 90W, 3000K, Type IV
RX1-090-E3-T4-G1 - RX Small, 90W, 3000K, Type IV, glare control
RX1-090-E4-T4-G0 - RX Small, 90W, 4000K, Type IV
RX1-090-E4-T4-G1 - RX Small, 90W, 4000K, Type IV, glare control
RX1-090-E5-T4-G0 - RX Small, 90W, 5000K, Type IV
RX1-090-E5-T4-G1 - RX Small, 90W, 5000K, Type IV, glare control
RX1-090-E7-T4-G0 - RX Small, 90W, 2700K, Type IV
RX1-090-E7-T4-G1 - RX Small, 90W, 2700K, Type IV, glare control
RX1-100-E3-T4-G0 - RX Small, 100W, 3000K, Type IV
RX1-100-E3-T4-G1 - RX Small, 100W, 3000K, Type IV, glare control
RX1-100-E4-T4-G0 - RX Small, 100W, 4000K, Type IV
RX1-100-E4-T4-G1 - RX Small, 100W, 4000K, Type IV, glare control
RX1-100-E5-T4-G0 - RX Small, 100W, 5000K, Type IV
RX1-100-E5-T4-G1 - RX Small, 100W, 5000K, Type IV, glare control
RX1-100-E7-T4-G0 - RX Small, 100W, 2700K, Type IV
RX1-100-E7-T4-G1 - RX Small, 100W, 2700K, Type IV, glare control

Download IES Package     Download PDF Package


RX1 030 C3 T5 G0 - RX Small, 30W, 3000K, Type V
RX1 030 C3 T5 G1 - RX Small, 30W, 3000K, Type V, glare control
RX1 030 C4 T5 G0 - RX Small, 30W, 4000K, Type V
RX1 030 C4 T5 G1 - RX Small, 30W, 4000K, Type V, glare control
RX1 030 C5 T5 G0 - RX Small, 30W, 5000K, Type V
RX1 030 C5 T5 G1 - RX Small, 30W, 5000K, Type V, glare control
RX1 030 C7 T5 G0 - RX Small, 30W, 2700K, Type V
RX1 030 C7 T5 G1 - RX Small, 30W, 2700K, Type V, glare control
RX1 040 C3 T5 G0 - RX Small, 40W, 3000K, Type V
RX1 040 C3 T5 G1 - RX Small, 40W, 3000K, Type V, glare control
RX1 040 C4 T5 G0 - RX Small, 40W, 4000K, Type V
RX1 040 C4 T5 G1 - RX Small, 40W, 4000K, Type V, glare control
RX1 040 C5 T5 G0 - RX Small, 40W, 5000K, Type V
RX1 040 C5 T5 G1 - RX Small, 40W, 5000K, Type V, glare control
RX1 040 C7 T5 G0 - RX Small, 40W, 2700K, Type V
RX1 040 C7 T5 G1 - RX Small, 40W, 2700K, Type V, glare control
RX1 050 C3 T5 G0 - RX Small, 50W, 3000K, Type V
RX1 050 C3 T5 G1 - RX Small, 50W, 3000K, Type V, glare control
RX1 050 C4 T5 G0 - RX Small, 50W, 4000K, Type V
RX1 050 C4 T5 G1 - RX Small, 50W, 4000K, Type V, glare control
RX1 050 C5 T5 G0 - RX Small, 50W, 5000K, Type V
RX1 050 C5 T5 G1 - RX Small, 50W, 5000K, Type V, glare control
RX1 050 C7 T5 G0 - RX Small, 50W, 2700K, Type V
RX1 050 C7 T5 G1 - RX Small, 50W, 2700K, Type V, glare control
RX1 060 C3 T5 G0 - RX Small, 60W, 3000K, Type V
RX1 060 C3 T5 G1 - RX Small, 60W, 3000K, Type V, glare control
RX1 060 C4 T5 G0 - RX Small, 60W, 4000K, Type V
RX1 060 C4 T5 G1 - RX Small, 60W, 4000K, Type V, glare control
RX1 060 C5 T5 G0 - RX Small, 60W, 5000K, Type V
RX1 060 C5 T5 G1 - RX Small, 60W, 5000K, Type V, glare control
RX1 060 C7 T5 G0 - RX Small, 60W, 2700K, Type V
RX1 060 C7 T5 G1 - RX Small, 60W, 2700K, Type V, glare control
RX1 070 C3 T5 G0 - RX Small, 70W, 3000K, Type V
RX1 070 C3 T5 G1 - RX Small, 70W, 3000K, Type V, glare control
RX1 070 C4 T5 G0 - RX Small, 70W, 4000K, Type V
RX1 070 C4 T5 G1 - RX Small, 70W, 4000K, Type V, glare control
RX1 070 C5 T5 G0 - RX Small, 70W, 5000K, Type V
RX1 070 C5 T5 G1 - RX Small, 70W, 5000K, Type V, glare control
RX1 070 C7 T5 G0 - RX Small, 70W, 2700K, Type V
RX1 070 C7 T5 G1 - RX Small, 70W, 2700K, Type V, glare control
RX1 080 E3 T5 G0 - RX Small, 80W, 3000K, Type V
RX1 080 E3 T5 G1 - RX Small, 80W, 3000K, Type V, glare control
RX1 080 E4 T5 G0 - RX Small, 80W, 4000K, Type V
RX1 080 E4 T5 G1 - RX Small, 80W, 4000K, Type V, glare control
RX1 080 E5 T5 G0 - RX Small, 80W, 5000K, Type V
RX1 080 E5 T5 G1 - RX Small, 80W, 5000K, Type V, glare control
RX1 080 E7 T5 G0 - RX Small, 80W, 2700K, Type V
RX1 080 E7 T5 G1 - RX Small, 80W, 2700K, Type V, glare control
RX1 090 E3 T5 G0 - RX Small, 90W, 3000K, Type V
RX1 090 E3 T5 G1 - RX Small, 90W, 3000K, Type V, glare control
RX1 090 E4 T5 G0 - RX Small, 90W, 4000K, Type V
RX1 090 E4 T5 G1 - RX Small, 90W, 4000K, Type V, glare control
RX1 090 E5 T5 G0 - RX Small, 90W, 5000K, Type V
RX1 090 E5 T5 G1 - RX Small, 90W, 5000K, Type V, glare control
RX1 090 E7 T5 G0 - RX Small, 90W, 2700K, Type V
RX1 090 E7 T5 G1 - RX Small, 90W, 2700K, Type V, glare control
RX1 100 E3 T5 G0 - RX Small, 100W, 3000K, Type V
RX1 100 E3 T5 G1 - RX Small, 100W, 3000K, Type V, glare control
RX1 100 E4 T5 G0 - RX Small, 100W, 4000K, Type V
RX1 100 E4 T5 G1 - RX Small, 100W, 4000K, Type V, glare control
RX1 100 E5 T5 G0 - RX Small, 100W, 5000K, Type V
RX1 100 E5 T5 G1 - RX Small, 100W, 5000K, Type V, glare control
RX1 100 E7 T5 G0 - RX Small, 100W, 2700K, Type V
RX1 100 E7 T5 G1 - RX Small, 100W, 2700K, Type V, glare control

RX1-BG

The RoadMAX RX1
30-100W Streetlight

Replace Cobraheads up to 200W
2,840-13,000 lumens

RX2-BG_callout

The RoadMAX RX2
70-220W Streetlight

Replace 150-400W Cobraheads
7,920-28,000 lumens

RX3-BG

The RoadMAX RX3
120-300W Streetlight

Replace 150-400W Cobraheads
13,200-39,700 lumens
